> Datalogic DS4600 laser barcode scanner reader DS4600A
Datalogic DS4600 laser barcode scanner reader DS4600A
* Medium Range - Reading Distance up to 550mm
* Light Source: Visible Laser Diode (658 nm)
* Maximum Resolution: 0.2 mm (8 mils)
* Maximum Reading Distance: approx. 550 mm @ 0.5 mm resolution (approx. 360 mm @ 0.25 mm resolution)
* Readable Codes (most popular): 2/5 family, Code 39, Code 93, Code 128, EAN/UPC, EAN 128
* Multilabel Reading: Up to 6 different codes in the same presence sensor phase
* Interfaces: One RS232, on SW programmable RS232 / RS485 Multidrop
* Baud Rate: Up to 115.2 Kbauds (both serial interfaces)
* Input Signal: Presence Sensor plus 2 programmable inputs (Optocoupled NPN/PNP transistor)
* Output Signals: 2 fully programmable digital outputs (Optocoupled NPN transistor open collector and emitter)
* Programming Method: Through serial interface (Winhost configuration)
* Operating Modes: On Line, Serial On Line, Automatic, Test
* LED Indicators: Ready, Ready Phase Active, Good Read, Data Transmit
* Laser Classification: IEC 825 Class 2
* Operating Voltage: 10 to 30 VDC
