Leblond makino 15" x 30" regal engine lathe 1982
Leblond Makino 15" x 30" Regal Engine Lathe 1982
Leblond Makino Engine Lathe
Model No. 15" Regal Servo-Shift
Swing Over Bed Ways: 15-1/2"
Swing Over Cross Slide: 9-1/2"
Maximum Distance Between Centers: 30"
Spindle Speeds: 45 - 1800 RPM
Hole Thru Spindle: 2-17/64" Diameter
Threading Range, Inch: 2 - 112 TPI
Threading Range, Metric: .25 - 12 mm/P
Feed Rates: .0018" - .104" / Rev.
Headstock & Tailstock Center Tapers: #4 MT
Overall Dimensions: 40" x 80" x 54" High
5C Collet Draw Tube & Collet Nose
7.5 Max. Rated HP, 5 HP Continuous Duty 230/460/3/60
Approximate Net Weight: 2,450 Lbs.
