Anritsu MN3650C digital modulator 800MHZ – 2.7 ghz
ANRITSU MN3650C DIGITAL MODULATOR 800MHz 2.7 GHz
Description: Anritsu (Formerly Wiltron) MN3650C Digital Modulator, 800 MHz - 2.7 GHz, DQPSK/GMSK. The Anritsu MN3650A Digital Modulator provides Pi/4 DQPSK and GMSK modulated signals in the 800 MHz to 2.7 GHz frequency range. The MN3650C can use either external data signals or IQ signals to perform modulation. It also accepts burst signals. By using the additional Option 01 Burst Function, these units can be used with additional TDMA systems. The rise/fall time of burst signal waveforms are moderate, that are equal to two symbols, adjacent channel leakage power measurement can be done as a continuous wave. The MN3650C is ideal for developing systems such as the GSM, NADC, PCN, PDC and PHS.
Features and specifications of the Anritsu MN3650C include:
Provides Pi/4 DQPSK and GMSK modulated signals
800 MHz to 2.7 GHz frequency range
Low phase noise may be used as an RF signal source to output high-accuracy, phase modulated signals with a phase error of 2 rms max.
GMSK modulation or a vector error of 1.5% rms max.
Can be used with additional TDMA systems
Rise / fall time of burst signal waveforms are moderate, and equal to two symbols
Adjacent Channel Leakage Power (ACP) measurements can be done as a continuous wave
