6N13S = ECC230 = 6AS7G triode svetlana 3 nos tubes
6N13S DOUBLE TRIODE TUBES Vintage USSR Svetlana.
6N13S (6H13C) - The double triode with separate cathodes and small internal resistance. It is intended for work in schemes of electronic stabilisation. Can be used as the amplifier of capacity of low frequencies in the target cascades collected under the duple scheme.
Made in USSR. Petersburg. Svetlana. 1973 year.
Service life not less than 500 hour.
Current of heat 2,5 0,25 And.
Pressure of the anode nominal (constant) 90 V.
Pressure of the anode limiting (constant) 250 V.
Pressure of the anode of each triode at the cold cathode,
Current of the anode of each triode nominal 80 32
Current of the cathode of each triode limiting 130
Pressure of a grid nominal (constant) - 30 V.
Return current of a grid 2 .
The capacity disseminated by the anode of each triode, limiting 13 W .
Resistance in a chain of a grid of each triode limiting 1 Mom.
Pressure between the cathode of each triode and a heater
Steepness of the characteristic of each triode 5,5 1,6 /V.
Internal resistance of each triode 460 Ohm
Capacity a grid of one triode - the anode of other triode 0,41 pF.
