New function generator 0.1HZ to 5 mhz in box
Function Generator 0.1HZ to 5 MHZ
* Output Waveforms: Sine Wave, Triangle, Square Wave, Positive and Negative Pluse, Positive and Nagative Ramp
* Output Impedance: 50 Ohm +/- 10%
* Amplitude: No less than 20Vp-p (open circuit)
* DC Voltage: 0 - +/- 10V continuously adjustable
* Symmetry Range: 90:10 - 10:90
* Rising Edge of Square: less than 50ns
* Distortion: Less then 1% at 10HZ-100KHZ
* Frequency Response: 0.1Hz - 100KHz, less than +/- 0.5dB
* TTL/CMOS Simultaneously Output
* Level: TTL low level less than 0.4V in pulse wave, high level less than 3.5V. CMOS low less than 0.5V in pulse wave, high level 5V - 14V continuously variable
* Rising Time: less than 100ns
* Output Voltage: -5V - 0V +/- 10
* Measuring Range: 1Hz - 10MHz > 10Vp-p
* Input Impedance: No less than 1 Mohm/20F
* Accuracy: less than 0.003% +/- 1 digit
* Line Power: 220V/110 +/- 10%; 50Hz/60Hz
* Dimension: 270 x 225 x 90 mm
