Ortec 4001A NIM BIN & 4002A 96W Power Supply System Used
Ortec 4001A NIM BIN & 4002A 96W Power Supply System
The ORTEC 4001A NIM Bin accommodates any equipment modules that have been manufactured to NIM standards as defined in DOE/ER-0457T. The 4001A Bin is recommended for use with the higher-current power supplies (like the 4002E). This bin is constructed of wire-form grids to ensure unimpeded ventilation for the instruments operated in the enclosure. The adjustment-free module guides are superior to the requirements specified in DOE/ER-0457T. These hardened steel guides feature generous openings and, because of their highly-polished nickel plating, offer a low friction coefficient. Aluminum alloy side plates are precision-formed and protected with a painted finish. The ORTEC 4001A Bin distributes all dc and ac power levels from the power supply to the module connectors through a wiring harness.
INSTALLED WIRING All connectors wired in parallel for +12 V, 12 V, +24 V, 24 V, +6 V, 6 V, high-quality ground, power-return ground, and 117 V ac, in accordance with DOE/ER-0457T pin assignments. An interface connector is supplied as required by DOE/ER-0457T for connecting control and power supply. Wiring Harness.
CONTROL PANEL A control panel with On/Off switch, power-indicating lamp, and thermal warning lamp for mating power supply. The thermal warning lamp is illuminated when the operating temperature approaches the design limit. Voltage test points are provided for convenient monitoring of the power supply outputs.
CONSTRUCTION Aluminum alloy side plates with nickel-chromium-plated handles on front-panel mounting flanges. Top and bottom members are high-tensile steel rod weldments, nickel plated, containing module guides. Rear connector plate is steel, cadmium plated.
