New industrial 4 speed 1000MM 40" wood turning lathe
* Maximum Length Of Cutting Feed - 40 inch (1000 mm)
* Max. Diameter - 14-1/4" (365 mm)
* Height Of Cutting Tool - 7" (178 mm)
* Motor Power - Single Phase 350 Watts
* Turning Capacity - 356mm (14 inches) max diameter over bed. 1000mm (40 inches) max between centers
* Pulley system - 4 speed V belt
* Spindle speeds - 1100, 1600, 2300, 3400 rpm
* Motor - 350W, 1400 rpm, AC 110V, 50/60 Hz
* Construction - Headstock, tailstock, foot, tool rest base and tool rest of heavy cast iron. Bed is of heavy steel tubing.
* Headstock - The drive spindle is No. 1 Morse taper and is also threaded .16. The outboard end of the drive spindle can also be used for large turning and is threaded .16 left hand. The pulley system and motor are mounted to the headstock.
* Tailstock - Slides along the full length of bed and clamps positively at any distance from drive spindle. The ram has a hand wheel advance of 2 3/8 inches with positive lock and is fitted with a No. 1 Morse taper
Local pick-up price is $119.99
