Wavetek acterna jdsu mts 5200E 5071 wdm dwdm anlyz 5200
* Wavetek MTS 5200e Mainframe With Options:
* Wavetek 5071 WDM Analyzer Module
* SM FC-FC Fiber Patch Cable
Wavetek MTS 5200e Mainframe With Wavetek 5071 WDM Optical Network Analyzer Module
The MTS-5200e Media Test Set is a field modular optical testers for fiber network installation, maintenance and troubleshooting. Two field interchangeable module slots allow users to quickly mix and match configurations to cover any fiber test application from 635 to 1625nm, to DWDM. The MTSe can easily be configured to include test modules for DWDM, OTDR LAN (ML), OTDR Multimode (MM), OTDR Short-haul (SR), medium-haul (DR), long-haul (HD), and very long-haul (VHD), 1625nm, and Optical Loss Testing with light sources and power meters.
Options are also available for Visual Fault Locators (VFL) and optical talk sets. Typical MTSe configurations combine a dual window 850nm to 1550nm dual port multimode and single mode OTDR for complete installation testing. Combining both a WDM test module and an OTDR module in the same unit can further extend test applications on DWDM networks reducing the number of testers required in the field. A comprehensive set of standard input/outputs facilitates documentation, file processing, and remote operation. A new Ethernet interface option facilitates and greatly simplifies the data transfer of large files to base.
* 5071 WDM OSA module Maintenance of C-band (1525 - 1570nm)
* Excellent wavelength accuracy ( 0.02nm typical) 12.5GHz Min channel spacing
* Portable mainframe MTS-5200 + 5071 WDM module
* RS-232 and Ethernet interface
MTS 5200e Mini-Optical Test Platform Features:
* Two field-interchangeable module slots
* Intuitive user interface with large display screen
* Long battery life and fast recharge time
* RS232C and Centronics I/O Installed
* Protective Travel Case Included
* AC Adapter Included: 100-250VAC Input, 12VDC Output
* Dimensions (L x W x H): 11.8 x 9.2 x 5.1 in
Equipped with a 5071 WDM module,the MTSe automatically provides all the necessary parameters to maintain a DWDM network. It can test for channel wavelength/ frequency, channel spacing, power, and optical signal-to-noise ratio (OSNR). By pressing a single key, the MTSe performs an acquisition immediately followed by an analysis of the existing channels. Measurement parameters are presented over the full spectrum in a waveform as well as in a tabular display. For easy analysis, a simple click on the table brings the relevant waveform center screen, where the zoom function provides a more detailed view.When a large number of DWDM systems need to be tested, a set of test sequences can be stored as a macro and implemented at the touch of a button saving time and resource.
* Fiber: Single Mode, 9/125 m
* Optical Interface: FC/APC
* Wavelength Range: 1525-1570 nm (C band)
* Power Range: -90 dBm at +30 dBm
