New usb to rs-485 signal data converter, in box
USB to RS-485 Signal Data Converter
The U-485 USB to RS485 Mini converter is a port powered small and convenient converter with no need for external power supply. U-485 can be used in point to point or point to multipoint networks. Connects up to 32 nodes, and can also connect to other RS485 connections. The communication distance can be up to 3000M at 4800bps or 2000M at 9600bps.
Support Windows 2000/XP/Vista, MAC OS-9/X, Linux 2.40 or above.
- USB port provide power, no need for external power supply
- Output is 2 wire half duplex RS485 connection
- Max communication distance 1000M at 115.2Kbps, 3000M at 4800bps
- Up to 32 nodes in network configuration
- Surge and static electricity protection up to 600W
- Working temperature: -20 to 70C
- USB V.1.1 and USB 2.0 compliant
- UART 300bps~1Mbps, auto tuning
This signal converter convert USB to RS-485.
- Support Windows 2000/XP/2000, MAC OS-9/X, Linus 2.40 or above
- USB supply power for the converter
