Complementary smt transistors design kit #1 (#3180)
Complementary SMT Transistors Design Kit #1 (#3180)
This is the very popular NPN & PNP Complementary SMT Transistor Design Kit #1. It includes the very popular complemetary SMT Transistor set of the Panasonic 2SB709A-R and the 2SD601A-R. Use these in place of 2N3904 and 2N3906. There are also 22 different values of SMT Resistors, SMT Capacitors, SMT Tantalum Capacitors, SMT Signal Diodes, SMT Potentiometers, and SMT LEDs.
There are enough different parts to build many different types of transistor circuits. Use these to build excellent H-Bridge drivers for miniature speakers, as small motor drivers, LED drivers, and much more. You get the following:
2SB709-A, PNP, Silicon, Switching, SOT-23
2SD601-A, NPN, Silicon, Switching, SOT-23
.0022uF, 50v, X7R, Ceramic, 1206
.0033uF, 50v, X7R, Ceramic, 1206
.0056uF, 50v, X7R, Ceramic, 1206
.01uF, 50v, X7R, Ceramic, 1206
.022uF, 50v, X7R, Ceramic, 1206
.033uF, 50v, X7R, Ceramic, 1206
.047uF, 50v, X7R, Ceramic, 1206
1.0uF, 35v, Case A, 20%, Tantalum
4.7uF, 10v, Case B, 20%, Tantalum
22uF, 16v, Case D, 20%, Tantalum
MMBD914, Silicon, Signal, SOT-23
BAV99, Silicon, Signal, SOT-23
Green, Clear Lens, 140 view, 0805
Red, Clear Lens, 140 view, 0805
Yellow, Clear Lens, 140 view, 0805
