Alkon 1/4"tube & 1/8"npt push-in brass elbow AP69-n-4X2
SERIES AP N- Nickel Plated Brass Tube Fittings for Plastic Tubing
Part# AP69-N-4X2 for 1/4 Tube OD and 1/8 NPT
TEMPERATURE RANGE NYLON SLEEVE: -40 F to 225 F
TEMPERATURERANGE BRASS SLEEVE: -40 F to 325 F
MATERIAL OF SHAPES (ELBOW , TEES): BRASS CA 377
MATERIAL OF STRAIGHTS: BRASS CA 360
MATERIAL OF SLEEVES: BRASS / NYLON
COMPATIBLE TUBING: IMPOLENE, SOFT METAL, POLYETHYLENE, POLYPROPYLENE, NYLON, POLYVINYL CHLORIDE, POLYALLOMER
When tubing is inserted into the fitting, it first passes through the brass tube support. This, combined with the action of the gripper, insures that the air brake hose assembly will safely exceed the tensile requirements of
FMVSS 571.106.The tubing then passes through the gripping teeth. The tubing continues beyond
the gripping teeth through the inside diameter of the lubricated "O" ring, which seals on the outside diameter of the tubing. The gripping teeth grab the tube. Pulling back on the tube only tightens the grip as the insert
moves onto the camming surface. Pressure through the tube also serves to tighten the grip. The tube bottoms against a positive tube stop in a cavity which keeps tube round to prevent leakage.
