60" X 144" USED 2-DECK STAINLESS ROTEX SCREENER 522A
MODEL 522A AASS. S/N R196458A. MAJOR WEIGHT: 367, MINOR WEIGHT: 183. 60 SQUARE FT OF SCREENING SURFACE AREA. STAINLESS STEEL BOX & PAN. ALUMINUM SCREEN FRAMES AND COVER WITH PNEUMATIC CLAMPS. AUTOMATIC SCREEN TENSION DESIGN. THE SCREENER IS CURRENTLY SUPPLIED WITH A 5/16" DIA. ALUMINUM PERFORATED DUAL PLATE DECK FOR THE UPPER SCREEN FRAME. THE LOWER DECK HAS A 9M S/S SCREEN INSTALLED. THREE OUTLETS IN PAN: (8" FINES OUTLET, 16" INTERMEDIATE OUTLET, & 8" OVERSIZE OUTLET). CABLE SUSPENSION DESIGN. 7.5 HP RELIANCE MOTOR, 1155 RPM, 230/460 VOLT, 254T FRAME. V-BELT DRIVE WITH GUARD. ADDITIONAL PHOTOS AVAILABLE UPON REQUEST.
* Items are also listed on other venues and are subject to prior sale.
