> Lot 6 numatics M10SA400H pneumatic micro-air valve 1.8W
Lot 6 numatics M10SA400H pneumatic micro-air valve 1.8W
LOT 6 NUMATICS M10SA400H PNEUMATIC MICRO-AIR VALVE 1.8W
Lot of 6 Numatics Micro-Air Valves Assembled / Mounted in 2 Set of 3 Valves Each with Tube + Fittings
MicroAir valves are designed for miniature automation applications blending high performance in a miniature package size. MicroAir offers high flow (Cv= .13) in a compact size - only 15 millimeters wide. Many plug-in features include a plug-in solenoid and optional speed control sandwich.
* Port Sizes: 1/8 NPTF & G, 10-32, 3B, M5
* 5 ported, 2 and 3 position, 4-way, spool & sleeve
* Flow Capacity: 6 SCFM @ 80 PSIG / 128 NI/m @ 6 bar
* Operating Pressure Range: 28" Hg. Vacuum to 150 PSIG / Vacuum to 10 bar
* Temperature Range (Ambient): -10 F to +115 F / -23 C to +46 C
* Direct solenoid actuated
* Plug-in solenoid with plug-in connector and LED
* Unlubricated or lubricated service
* Integral speed control available
