Digital temperature controller hot/cold 24 vdc
DIGITAL TEMPERATURE CONTROLLER HOT/COLD 24V
THIS DEVICE WITH ONE POINT OF INTERVENTION ONLY.
THIS CAN BE USED FOR BOTH HOT AND COLD APPLICATIONS, AT TEMPERATURES FROM -27 TO +62 DEGREES CENTIGRADE.
COMPLETE WITH A NTC THERMOSTATIC PROBE.
INPUT AND OUTPUT RELAY FOR THE LOAD MANAGEMENT.
EASY TO CALIBRATE SENSOR FROM -5 TO +5 DEGREES CENTIGRADE AND COMPRESSOR PROTECTION TIME CAN BE DELAYED FROM 0 TO 15 MIN WITH THE INBUILT TIMER.
THE VALUE OF THE PROBE READING IS VIEWED ON A DIGITAL DISPLAY BY THREE DIGITS AND A MINUS SIGN COULD BE FLUSH FITTED IN THE DASH OF ANY VEHICLE.
THIS DEVICE HAS MANY NUMBER OF APPLICATIONS SUCH AS DOMESTIC, INDUSTRIAL AND AUTO MOBILE USE. ALSO COULD BE USED AS AN ENERGY SAVING DEVICE TO SAVE OUR ENVIRONMENT AND MAINTAIN THE OPTIMUM OUT PUT OF YOUR PLANT AND MAINTAINING THE REQUIRED TEMPERATURE FOR YOUR PRODUCT AT ALL TIME.
HIGHLY RECOMMENDED TO USE IN HEATED/REFRIGERATED TRUCKS.
-25o C to +60o C (Factory defaults = 4o C)
0.5o C to +10o C (Factory defaults = 4o C)
0-15 min. (Factory defaults = 3 min)
-5o C to +5o C (Factory defaults = 0o C)
NTC sensor with black PVC/1.5 m
Panel SNAP-IN power board wall mounted
