New logixpro 500 - rs logix 500 training
LogixPro 500 - This is the best PLC Programming Software available today !
I have trained Supervisors, Foreman, Journeyman, and Apprentices in Seminars and Classes with this Software.
It was developed to assist people in learning or improving their PLC Programming Skills and was designed to Simulate Allen Bradley RS Logix 500.
I've included 30 Working Solutions as listed below.
They are ready to load and run with-in the LogixPro 500 Software.
Eventhough I've included the " Working Solutions", You still have the control or choice to program from the start, make changes to the Solutions, and Save at any point.
The advantage of having these working Solutions is that you can watch the program run which will make the learning process easier and more simple to understand.
Each Solution has Line Description and Device Identification.
The LogixPro 500 CD is the Key and must be in the drive to work.
The LogixPro 500 is New, the Full Version and has complete owner rights for Upgrades, Tech Support, Etc
The Specifications say Microsoft Windows 95/98/NT/2K/XP installed,
It does work with Microsft Vista - Select " Run as Administrator. "
Logixpro may work with Mac under certain conditions, "HOWEVER", The decision to try is your own at your own risk.
3) Silo Automated Filling System
6) Intersection Traffic Light Control
2) Advanced Batch Mixing System
Software Simulations for Industrial Training
Programmable Process Simulations
ProSim-II Simulations is an interactive educational tool, developed to assist students in the acquisition of the programming skills used in the control of process oriented equipment and systems. Although designed primarily for use with Programmable Logic Controllers (PLCs), the flexible interface of the ProSim package readily allows it to be used with any computer programming language which supports ActiveX objects in a MS Windows environment.
Typical industrial processes such as material transfer operations using a conveyor or batch mixing tanks complete with pumps and metering are graphically displayed on the screen. The displayed processes are fully animated and when used with a PLC or PLC emulator, will respond to the signals of the PLC in the same manner that actual process equipment and sensors would respond. For example, a properly addressed PLC output can be used to start a pump on a mixing tank. Once started, visual indication of the pump's rotation and fluid flow will appear on the computer screen. In addition, a digital signal representative of fluid flow would be transferred back as an input to the PLC program.
......... And More On The Way.! ........
Industrial Applications Software (Simulations):
The ProSim-II software includes the following simulated processes:
(1) Hardware I/O and BCD Simulator/Tester/Demonstrator
* 32 switches (2x16), user selectable by type
* 32 lights (2x16), user selectable color
* 4 Hexidecimal LED displays
* 4 Binary Coded Decimal Thumbwheel Switches
(2) Motorized Garage Door simulation
* Operator Station Panel and controls
* Up, Down and Stop Push-button Station
* Run, Open, Shut Panel Indicators
* Open and Closed limit swithes
* Conveyor with position sensors (photo switch)
* Hopper with motorized chute control
(4) Intersection Traffic Light Control Simulation
* 2-way traffic intersection system
* 2 Vehicle Sensor Grid Switches
(5) Batch Mixing system Simulation
* 2 flow meters on filler lines
* 2 level sensors (hi and low)
* 1 gas fired heater (controlled valve)
(6) (BCD) Binary Coded Decimal Simulator
* 2 Hexidecimal LED displays
* 2 Decimal/Hexidecimal Thumbwheel Switches
* User Option of Decimal or Hexidecimal Modes
* Real-time Bit Indication Status
(7) (Comp) Dual Compressor Control Simulator
* User adjustable Air-flow utilization.
* 2 Pressure Switches (adjustable setpoint and span)
* 2 Binary Coded Decimal LED displays
* 2 Binary Coded Decimal Thumbwheel Switches
(8) 4 Floor Elevator Simulator
* Car mounted Control Panel c/w switches and lamps
* Bi-directional Door Motor c/w limit switches
* Bi-directional Elevator Motor c/w shaft encoder
* 6 Wall mounted service request switches c/w built in lamps.
* 4 Wall mounted plus 1 car mounted floor indicator lamps (quad)
* Full Operator Control Panel
* Presence, Bottle Size, and Broken Bottle Detection Switches
* Scrap Divertor Gate, and Scrap Grinder
* Scrap Boxing Conveyor Line
* IBM compatible PC 486 100Mhz
* VGA color display using default small fonts
* Microsoft Windows95/98/NT/2K/XP installed
