New brand dake zip 28 horizontal miter band saw
Unique design makes this bandsaw a real problem solver and an exceptional value.
These Johnson mitering horizontal bandsaws will miter up to 60 to the right, and anywhere in between. They also feature head down feed, multimode cutting, quick set cam-activated vises, direct drive, and a heavy cast head frame.
Solid rectangle 90 : 9 5/8" x 3"
Solid rectangle 45 : 5.5"x5.5"
Solid rectangle 60 : 3.25"x 3.25"
Floor space left to right: 39 3/8"
Floor space front to back: 68 7/8"
Easily set the most appropriate blade and head descend speed according to the stock material, size and shape for maximum efficiency.
Quick set cam-activated vises. Adjustable vise with handwheel for initial set up and quick release cam lever for repeat cutting.
Drive system. Direct drive means full power to the drive wheel without horse power loss through belts and pulleys.
Low maintenance without belts and pulleys.
Miter up to 60 to the right, and anywhere in between. The head, NOT the material, rotates for angle cutting.
* Electric coolant pump with flow control
* Quick set cam action type vises
* Hydraulic regulated head down feed
* CE certified electrical low voltage controls with thermo overload and low voltage coil
* Door interlocks and end of cut shut off
* Mechanical blade tensioning (blade breakage shut off)
* Adjustable manual head return
Material support roller and multimode feature
