External dimension: L89 W70 H28 mm
Packing size: L160 W90 H51 mm
Output current: <4A(each channel)
Adopt two sheath wires as connecting wires, meanwhile, brown wire + blue wire -Load output interface:
Adopt four sheath wires as connecting wires, meanwhile, black wire + brown wire R yellow wire G blue wire B
1. Connect the load wire at first, following by the power wire; Please ensure short circuit can not
occur between connecting wire before you turn on the power;
2. Adopt film button control, there are six buttons altogether, and every key-press function as
On/Off: In any state, you could turn on or turn off the output of controller;
Mode: Pattern function key, you could choose the different changing mode;
Brightness +: Brightness control of output signal, the brightness progression will add one when
you press the button every time;
Brightness -: The brightness progression will subtract one when you press the button every
* 1 x IR Wireless Infrared RGB LED Remote Controller 6-key 4A
