Test products inc P200B oscilloscope probe
Test Products Inc P200B Oscilloscope Probe
The Probe tip, head, and BNC/cable of the P200B Repairable Oscilloscope Probe can be replaced without soldering. Compensation adjustment has been placed in the BNC to eliminate noise or hum pickup. Attenuation: X10 Cable Length: 1.4 m Input Impedance-Resistance: 10 Mohm Input Impedance-Capacitance: 12pF Bandwidth: 200MHz Risetime: 1.8 ns Maximum Input V: 600V Compensation Range: 15-35pF
