> 90" tbl 50HP spdl kearney&trecker 4CSM universal mill,
90" tbl 50HP spdl kearney&trecker 4CSM universal mill,
90" Tbl 50HP Spdl Kearney&Trecker 4CSM UNIVERSAL MILL,
90" Table 50HP Spindle Kearney&Trecker 4CSM UNIVERSAL MILL, 2 Arbor Supports, #50 Taper, Rapid Trave
KEARNEY & TRECKER HORIZONTAL MILL
MODEL: 4CSM, S/N: 1-6733, NEW: 1953
TABLE SIZE ........................ 17-1/2" X 90"
LONGITUDINAL ................ 42"
CROSS ....................... 14"
VERTICAL .................... 18"
TAPER IN SPINDLE .................. #50 N.S.T.
SPINDLE SPEEDS, HORIZ & VERT (48) . 25 - 1,250 R.P.M.
LONGITUDINAL AND CROSS (32) . 3/8 - 90 I.P.M.
VERTICAL (32) ............... 3/16 - 45 I.P.M.
APPROXIMATE WEIGHT ................ 12,500 LBS.
- DOUBLE ROUND OVERARMS AND (2) ARBOR SUPPORTS
- POWER RAPID TRAVERSE, ALL DIRECTIONS
- AUOTMATIC LUBRICATION SYSTEM
- 50 / 25 H.P. TWO SPEED DRIVE MOTOR WITH ELECTRICAL CONTROLS
