Nichols 8 tool room hand feed horiz. milling machine
Nichols 8 Tool Room Hand Feed Horiz. Milling Machine
Nichols Hand Feed Milling Machine
Longitudinal Table Travel: 19"
Knee Vertical Adjustment: 11"
Rise & Fall of Spindle Head: 4.5"
Max. Distance Spindle to Table: 14.75"
Spindle Speeds, (16): 60 - 2,875 RPM
Machine Floor Space: 58" x 58" x 60"
2HP Spindle Motor 440/3/60
Approximate Net Weight: 2,000 lbs.
