New 30 ton brand electric-hydraulic h-frame press
30 TON BRAND NEW ELECTRIC-HYDRAULIC H-FRAME PRESS
30 TON PRESSMASTER H-FRAME HYDRAULIC PRESS
NEW - IN STOCK FOR IMMEDIATE DELIVERY
RATED CAPACITY ............................... 30 TONS
STROKE ....................................... 8"
BORE ......................................... 5"
RAM SPEED (SEC/INCH): ADVANCE ................ 7
DISTANCE BETWEEN POSTS (RIGHT TO LEFT)........ 30"
DISTANCE BETWEEN POSTS (FRONT TO BACK)........ 10"
MAXIMUM DISTANCE FROM BED TO RAM ............. 33"
OVERALL HEIGHT ............................... 67"
OVERALL WIDTH ................................ 40"
OVERALL DEPTH ................................ 24"
WEIGHT ....................................... 850#
MANUFACTURED IN CANADA WITH QUALITY US & CANADIAN COMPONENTS
OPEN SIDES TO FACILITATE WORK ON LONG PIECES
WINCH OPERATED ADJUSTABLE TABLE HEIGHT
SAFETY VALVE FOR OVERLOAD PROTECTION
FLAT RAM NOSE TO ALLOW USER TO ADAPT THE PRESS TO A SPECIFIC JOB.
BALDOR 2 HP, 230 VOLT MOTOR, TOTALLY ENCLOSED FAN COOLED
- FLOW CONTROL - TO MATCH RAM SPEED TO JOB @ $600.00
- PRESSURE REGULATOR - TO CONTROL THE AMOUNT OF PRESSURE
- FOOT PEDAL-ELECTRIC SOLENOID VALVE @ $2,500.00
- ADJUSTABLE STROKE CONTROL C/W FOOT PEDAL-ELECTRIC SOLENOID
- DOUBLE-ACTION PERMITS PULLING AS WELL AS PRESSING RAM
- EXPANDED DISTANCE BETWEEN POSTS OF 42" @ $800.00
- HIGH SPEED PACKAGE, 5 HP MOTOR COMPLETE WITH HIGH VOLUME
CAN BE INSPECTED IN OUR HARRISON, NJ WAREHOUSE
