Wilo stratos 1.25 x 3-30 230V ci variable speed pump
SELF REGULATING VARIABLE SPEED CAST IRON PUMP
THE STRATOS IS ULTRA EFFICIENT AND COULD SAVE UP TO 80% OF ENERGY USED BY STANDARD PUMPS
Maximum Delivery Head: 20(ft), 9(m)
Maximum Flow Rate: 57.2(USGPM), 13(m3/h)
Temperature Range: 14 F - 230 F (-10 C 110 C)
Maximum Working Pressure Pmax: 145PSI
Ambient Temperature: 104 F (40 C)
* EC motor (Electronically Commutated)
* Pre-selectable control modes ?p-c, ?p-v, ?p-T for optimum load adjustment
* Pre-selectable speed for constant operation
* Automatic setback operation for additional energy savings
* Dual pump operation (master/slave, parallel and stand-by operation)
* Red button technology for very easy operation
* Graphic pump display with rotatable display adjustable from US units (default) to metric
* Programming via manual "red button" or Wilo IR (infra-red) monitor
* Infra-red interface for Wilo IR monitor
* Integrated motor protection
* BMS interfaces with optional IF (interface) module (LONworks and 0-10 Vdc)
* Pump communication with IF (interface) module that can be easily retrofitted: ideal external operation
* Fault lamp and contact for collective fault signal
* Cataphoretic coated pump housing
* Pump flanges - 2 bolt oval 1 " and 1 " 4 bolt 2" pump flange 4 bolt 3" 125 # raised face ANSI
* Wet rotor circulator with EC motor and integrated automatic capacity adjustment
* Red button technology and graphic display
* Motor protection with electronic overload protection (min/max voltage, max temp, dry run, overload)
* Interface connection for extending built in functions, for building automation (BA) systems and external control
* Impeller with three-dimensional curved blades and rotor can using carbon fibre compound material
