> 1972 tachella 612UA 10" x 24" universal id/od grinder
1972 tachella 612UA 10" x 24" universal id/od grinder
1972 TACHELLA 612UA 10" x 24" UNIVERSAL ID/OD GRINDER
10" X 24" TACCHELLA "ITALIAN" PRECISION
(ORIGINALLY IMPORTED BY WARNER & SWASEY)
MODEL: 612UA S/N: 3580 NEW: 1972
MAXIMUM SWING OVER TABLE............... 10"
TRAVERSE SPEED......................... 4" TO 276" I.P.M.
SWIVEL TABLE GRADUATED (DEG. INCLUDED
ANGLE)................................. 10 DEGREES
GRINDING WHEEL ........................ 14" DIA.
SWIVEL RANGE .......................... +/- 90 DEGREES
(2) GRINDING WHEEL SPINDLE SPEEDS...... 1640/1900 R.P.M.
INFEED HANDWHEEL, 1 GRAD. = ........... 0.0002"
AUTOMATIC INFEED @ TABLE REVERSAL,
ON DIA. .............................. 0.0005" TO .002"
PLUNGE GRINDING, FEED RATE RANGE ...... 0.0005" TO .070"
MIN./MAX. PLUNGE CUT DEPTH ............ 0.004" TO .16"
RAPID HYDRAULIC INFEED STROKE.......... 1- 1/2"
INFINITELY VARIABLE WORKHEAD SPEEDS ... 30 TO 600 RPM
WORKHEAD TAPER......................... #3 MT
DIA. OF HOLE, WORKHEAD SPINDLE......... 1- 7/16"
WORKHEAD SWIVEL RANGE.................. +/- 90 DEGREES
TAILSTOCK TAPER........................ #3 MT
TAILSTOCK STROKE ...................... 3/4"
APPROX. DIMENSIONS .................... 64" X 60" X 70"H
APPROX. WEIGHT ........................ 5,200 LBS.
SWING DOWN INTERNAL GRINDING ATTACHMENT w/SPINDLE
WHEEL BALANCING STAND WITH ARBORS
-SINGLE LEVER AUTO CYCLE CONTROL
-DUAL RATE (COARSE & FINE) PLUNGE INFEED
-RAPID WHEELHEAD AVANCE & RETRACTION
SPARKOUT TIMER (0 TO 60 SECONDS)
14" x 2"W GRINDING WHEEL PRESENTLY ON MACHINE
INFINITELY VARIABLE ELECTRONIC SPEED CONTROL FOR WORKHEAD
MOTORS ON MACHINE ARE DUAL VOLTAGE (220/440 VOLTS)
ITALIAN BUILT MACHINE, SUPERIOR QUALITY! **
