Vectron 12.8MHZ tcxo stratum 3 oscillator
Vectron 12.8MHz TCXO Stratum 3 Oscillator
The 6755 has been optimized to work with the Semtech Chip ACS8510 SETS to meet the requirements of Bell Core specification GR-1244-CORE and ITU G.813.
It has been designed to meet the Frequency vs Supply requirement of 0.05 ppm over any 5% change in Supply from a minimum of +3.135 Vdc to a maximum of +5.5 Vdc.
* 12.800 MHz output frequency
* Low Current Draw Consumption: <20 mA
* Aging to <4.0 ppm for 20 years
* Package: 1.0x 1.15x 0.395(25.40x29.21x10.03mm)
* +3.3 Vdc (operable over +3.135 Vdc to +5.5 Vdc)
