New pc-usb dso-2090 usb pc-based digital oscilloscope
DSO-2090 USB has the following features: 40MHz analog bandwidth, 100MHz real-time sampling
DSO-2090 USB uses USB that supports plug'n play, with 12Mbp communication speed.
* Best perormance for your dollar
DSO-2090 USB uses has many features that are comparable to the high speed stand-alone DSOs. But it costs a fraction of the price.
* No external power required
DSO-2090 USB does not need an external power source, because it is bus-powered from USB
DSO-2090 USB is easy to use. It is intuitive and easy to understand.
You can change DSO-2090 USB screen size as you need.
* Various data format processing
DSO-2090 USB can save wavrfrom in the following formats: text file, jpg/bmp graphic file, MS excel/wor
100MSa/s PC USB Digital Storage Oscilloscope DSO-2090
Real-time sampling: 100MS/s using one channel, 50MS/s using two channels
10mV-5V/div @ x1 probe(10mV,20mV,50mV,100mV,200mV,500mV,1V,2V,5V/div1,2,5 sequence)
35Vpk(DC + peak AC < 10 KHz, without external attenuation)
4ns/div - 1h/div(4ns,10ns,20ns,40ns,100ns,200ns,400ns,1us,2us,4us,10us,
20us,40us,100us,200us,400us,1ms,2ms,4ms,10ms,20ms,40ms,
100ms,200ms, 400ms,1s,2s,4s,10s,20s,40s,10m,20m,
Realtime sampling:4ns/div - 400ms/div
Edge trigger: Rising edge, falling edge.
Vp-p, Vmax, Vnin, Vmean, Vrms, Vamp, Vhigh, Vlow,positive overshoot,
negative overshoot, cycle mean,cycle rms, period, frequency,
positive pulse width,negative pulse width, rise time(10%-90%),fall time(10%-90%),positive duty cycle, negative duty cycle
Time/frequency difference, voltage difference Frequency only in FFT mode
Addition, Subtraction, Multiplication, Division
Rectangular, Hanning, Hamming, Blackman Window
Universal Serial Bus(USB2.0,1.0)
No external power source required.
* 2 X 60MHz/4MHz Clip Probes
