> Panasonic micro-imagechecker a series A100 main unit
Panasonic micro-imagechecker a series A100 main unit
The A series is the universal compact system for grey-scale processing. Proven in a thousand applications, it is safe and reliable. With a great variety of different inspection elements, it can handle all the common image processing tasks. Product Condition:Used Very Good
The A series is the universal compact system for grey-scale processing. Proven in a thousand applications, it is safe and reliable. With a great variety of different inspection elements, it can handle all the common image processing tasks. The Micro-Imagechecker A-Series has a menu-based user interface which makes it easy to set the inspection parameters for your individual inspection task - even without programming skills. With just four buttons, you can make all needed adjustments in a short time.
* Two serial (RS232) interfaces
* 14 digital outputs and 11 inputs
* With just four buttons, you can make all needed adjustments in a short time
* CPU: 32-bit RISC CPU (360 MIPS)
* Resolution: 512 x 480 pixels x 256 gray values
* Serial 2 x RS232C (e.g. 1 x for PLC, 1 x for PC)
* Baud rate: 1200 115kbaud
* Parallel (PhotoMOS) 14 out, 11 in, e.g. for type change via PLC, removable screw terminal
* Supply voltage: 24V DC (< 0.7A)
* Dimensions (H x W x D): 120 x 40 x 74mm
* Micro-Imagechecker A Series A100 Main Unit
