> 100X measuring portable - field use microscope
100X measuring portable - field use microscope
Call TrueVision Microscopes now! Toll free (***)-215-3795
Compound light microscope for use with viewing biological specimens on slides.
Photographs taken using different digital camera held to eyepiece of this microscope.
Click to enlarge image! Photo Thru 10x Eyepiece
USB computer connected camera included. Computer/Laptop not included.
Shape of microscope camera may vary from what is shown.
Copyright 2005 TrueVision Microscopes.
All photos, style, and text are copyrighted by
TrueVision Microscopes. Any unauthorized
infringement will be pursued with legal action.
+ RETICLE AND BATTERY LIGHT + USB COMPUTER CAMERA
* Monocular Shop-Field Microscope with Measuring Capability!
* Compact and Lightweight - Great for Field Use!
* Easy to Use! Simply set the scope over the surface to view!
* Surprisingly Good Optics for an Incredible Price!
* Measuring Reticle Built into Eyepiece.
* Reticle Specs: 10mm length subdivided into 100 divisions, 0.1mm Resolution on the Reticle (not actual resolution of the scope).
* Actual Measuring Specs: Each reticle division represents 0.01 mm actual true size when viewed through the scope eyepiece. For example, if a scratch on the surface of your specimen is 18 reticle markings wide, then that represents 0.18 mm (18 x 0.01mm) wide scratch.
* Includes a Complete Microscopy System to Capture Live Digital Video on Your Computer!
* USB Connected Microscope Camera is Included!
* WARNING! Cheaper USB Cameras DO NOT include a Reduction Lens System! You Will Be Disappointed with a unit that is Missing this Critical Lens. The Lens is Necessary to Reduce the Severe Cutting of Field done by the CCD chip. This Unit INCLUDES a 0.5x Reduction Lens!
* Turn Your Computer into a Microscope Video Image Capture System!
* Take High Quality Still Color JPG Images, Sizes: 640x480 and 320x240 Pixels!
* Easy Connection to your Computer via USB!
* Great Optical System for Capturing High Quality Clear Digital Images!
* SIMPLE! - Just Insert Camera, Load the Included Software and Plug into your Computer's USB Port!
* Eyepiece Included: Wide Field 10x.
* 100x Total Fixed Magnification.
* Battery Operated Pen Light (Uses 2 AA Batteries, Not Included).
* The Pen Light is Adjustable, and on an Angle to Provide Maximum Lighting Efficiency and Minimum Glare.
* Focusing Knobs Raise and Lower the Scope and Objective.
* Focusing Travel Distance: 35mm.
* Field of View: 1.7 mm. This is the Actual Distance Across Your Eyepiece Viewing Diameter. For example, a 1.7mm long specimen will completely fill your viewing area. Note: photos taken through the eyepiece cut the field of view since a CCD Camera has a smaller field of view than a human eye.
* Comes with Carrying Case with Precut Foam Padding.
* Manufactured under ISO: 9001 Standards.
* Protective Molded Styrofoam Container.
* Precision Ground Glass Lens.
* Quality Construction, Metal Frame.
* Warranty is 5 years on all microscope equipment.
* The microscope warranty covers problems arising from normal usage.
* We will repair or replace your defective microscopy equipment as needed during the warranty period.
RISK FREE - MONEY BACK GUARANTEE - 14 DAYS TRIAL PERIOD!
QUALITY SERVICE AFTER THE SALE!
If you have questions or issues after the sale, please call our technicians. They are just as happy to talk to you after the sale as before. We hire skilled sales technicians who are required to have a Bachelor s Degree in biology, engineering, or related science fields.
