Digital light meter 100K lux tester lcd camera photo
Digital Light Meter 100k Lux Tester LCD Camera Photo
20,000 Lux range : reading x 10
100,000 Lux range : reading x 100
< 10,000 Lux. : +/- 4% reading +/- 0.5 f.s.
> 10,000 Lux. : +/- 5 + 10 digits (calibrated to standard incandescent lamp at color
6.Temperature Characteristic : +/- 0.1% / C
7.Test rate : 0.2 times / sec.
8.One silicon photo diode with filter
9.Operation temperature-humidity : 0 C to 40 C (32 F-104 F) 0-70% Rh;
10.Storage temperature-humidity: -10 C to 50 C (14 F-122 F) 0-80% Rh
Indication of " 1" (2,000 Lux/20,000 Lux),
Indication of "OVER" (100,000 Lux)
106 x 57 x 26mm (photo detector),
power Supply : one 9V battery (included)
