Commercial roll up door - 12' x 14' - 2000 series
Commercial Roll Up Door - 12' x 14' - 2000 series
Please note that sizes are given width by height. For example, a 10' by 12' door is 10 feet wide and 12 feet high.
2000 Series: Light-Duty Commercial-Grade Door
The 2000 Series is the right choice for light-duty applications requiring frequent usage such as warehouses, freight terminals, car washes, machine shops, auto body shops and much more. The 16-gauge, 12 drums allow for easy retraction. These doors are low-maintenance, which is what every owner wants in a quality door. These commercial-grade steel curtain roll-up doors are designed to meet and/or exceed operational requirements for commercial doors with little or no maintenance.
* Maximum opening size of 12 x 18
* NOTE: The 2000 is not rated for wind loads. Please see the 2500 or 5000.
* 6063-T6 aluminum extrusion
* 2 x 1 galvanized angles
* Stainless steel nuts and bolts
* 1 5/16 O.D. steel axle, 14-gauge
* 11-gauge axle on doors over 10 wide
* Utilizes 12 , 16-gauge drums
* Shielded steel ball bearings in drums
* Adjustable bolt on head stop
* Pre-punched for lock and attachment fasteners
* Saddle clamps with set fasteners
* 10-gauge slide locks; 2 per door
* 16-gauge step plate; 2 per door
* Doors up to 10 have 20 of headroom
* Doors 10 to 14 have 22 of headroom
* Doors over 14 have 24 of headroom
Options (available at additional cost)
* 1900 Series low overhead option
