> 10" swg 20" cc k.o. lee C1020ND cnc od grinder
10" swg 20" cc k.o. lee C1020ND cnc od grinder
10" Swg 20" cc K.O. Lee C1020ND CNC OD GRINDER
10" Swing 20" Centers K.O. Lee C1020ND CNC OD GRINDER
K.O. LEE CNC UNIVERSAL CYLINDRICAL GRINDER
MODEL: C1020ND, S/N: 4101-12-04, MFG. 2004
Swing:.......................... 10"
Distance Between Centers:....... 20"
Max. Longitudinal Travel:....... 24"
Swivel:......................... +/- 7 degrees
Feed Rate:...................... .01-400 I.P.M.
Swivel:......................... 135 Degrees
Speed, infinitely variable in two ranges:. 35-700 R.P.M.
Through Hole I.D.:.............. 1.3"
Center taper:................... 48"
Feed Rate:...................... .01-200 I.P.M.
Maximum Travel:................. 7.5"
Grinding wheel size:............ 14" x 5" x 1.5"
Spindle speed:.................. 1,755 RPM
Spindle Diameter:............... 3.5"
Equipped with:Plunge, Traverse, Shoulder Grind, Contour Dress and Grind, Taper Dress and Grind,
and Fillet Radius Dressing & Grinding capabilities
#1020 NUM simultaneous two-axis CNC control with RS-232 & keyboard ports and
manual pulse generator. The control provides graphical representation of grinding
and grinding dressing cycles. A standard 2D CAD package enables the control to be
programmed at the machine for complex wheel forms and contour generation of the
Table and wheelhead driven by AC digital servo motors
Pre-loaded linear guideways on the table and wheelhead axes
AC variable speed headstock motor with #5 Morse Taper/#3 Morse Taper center
adapter, 6" diameter three-jaw chuck, and diamond dresser mounted on back
(2) Dead centers assemblies for headstock providing live and dead center grinding
Adjustable spring loaded tailstock with #3 Morse Taper center
MOVOMATIC electronic gap eliminator
Optional spray hood (complete enclosure)
GRAYMILLS external coolant pump and tank with paper band filtration
Machine Operation and Maintenance manual
5 H.P. 3/60/460 volt wheelhead motor
Approximate Weight: 3,900 Lbs.
Approximate Dimensions: 107" L-R x 85" F-B x 70" H
