Bell & gossett hft-15 expansion tank replaces 15 extrol
The Series HFT tank is designed to absorb the force of thermal
expansion of heating water and to maintain proper pressurization
in a closed hydronic system. The heavy duty butyl
diaphragm separates system water from the air in the tank
preventing water logging problems.
SYSTEM CONNECTION 1/2" NPT - 12-5/8" HEIGHT - 8" DIAMETER -
Maximum working pressure . . . . . . . . . . . . . .100 PSI (689kPa)
Maximum operating temperature . . . . . . . . . . . . .240 F (115 C)
Shell . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Carbon Steel
Diaphragm . . . . . . . . . . . . . . . . . . . . .Heavy Duty Butyl Rubber
EXACT REPLACEMENT FOR AMTROL EXTROL #15 EXPANSION TANK. ALSO A FUNCTIONAL REPLACEMENT FOR FLEXCON HTX 15, VENT-RITE VR15, WATTS ET-15, STATE ET-20, ELBI XT-15, WILKENS HXT-15
