> New integra 202-79-01 pneumatic diaphragm valve 1/4"
New integra 202-79-01 pneumatic diaphragm valve 1/4"
* PRESSURE RANGE: 29" Hg VACUUM (980 mbar) TO 40 PSIG (275.8 kPa) AT 0 OUTLET PRESSURE (PORT 2)
* 35 to 150 F (2 to 65 C), AMBIENT
* 35 to 300 F (2 to 150 C), FLUID
* PNEUMATIC SUPPLY PRESSURE: 50 PSIG (344.7 kPa) MINIMUM TO 70 PSIG (482.6 kPa) MAXIMUM
* PNEUMATIC SUPPLY PORT: 1/4" FNPT PUREBOND FUSIBLE PIPE
* MATERIALS: ALL WETTED PARTS ARE PFA. EXTERIOR ACTUATOR PARTS ARE PVDF. INTERIOR ACTUATOR PARTS ARE PVDF & VITON
* VALVE TYPE: NORMALLY CLOSED
* MANUFACTURER: ENTEGRIS/INTEGRA/FLUOROWARE
* INCLUDED IN ORIGINAL BOX WITH COMPLETE SPECIFICATION SHEET
ESTIMATED RETAIL PRICE: $163.94
