Humphrey air hsda-40 pneumatic swing cylinder assembly
Humphrey Air HSDA-40 Pneumatic Swing Cylinder Assembly
Provides linear and rotary motion, either simultaneously or alternately. SImplifies design; one actuator does the work previously required by a cylinder and rotary actuator. Two bore sizes to choose from: 1-inch (25mm) and 1 1/2-inch (40mm). Four different swing angles: 45 degrees, 90 degrees, 135 degrees and 180 degrees. Sensor switches can be applied to detect both linear and rotary functions.
