> New uei C75KIT eagle combustion analyzer w/printer
New uei C75KIT eagle combustion analyzer w/printer
UEi Eagle Series Combustion Analyzer #C75KIT
The C75KIT is a complete solution for technicians working to set and maintain optimum efficiencies for boilers or furnaces. This kit includes the innovative and feature packed C75 Combustion Analyzer. Equipped with smart and useful features like the DMM style rotary selector, a real time clock and a magnet built-in to the boot, the C75 captures and calculates data with professional accuracy and ease. The KMIRP2 Thermal Printer. supports a new and compact design and communicates with the C75 via an infrared link. It too has a built-in magnet making it the perfect companion to the C75 analyzer. This kit also includes a professional grade flue probe with a stainless steel shaft, an AC power adapter, an extra particle filter, and an extra roll of thermal paper all packed in a compact and convenient soft carrying case. Three year limited warranty (Two year limited warranty on sensor).
* C75KIT Combustion Analyzer with stainless steel probe
* Unique Digital Multimeter style rotary selector
* Protective boot with integral magnet
* Large 2 line backlit display
* Gross / net efficiency
0.2% (Using dry gases at STP)
10 ppm <100 ppm (Using dry gases at STP) 5% reading
Natural gas, Light Oil, Propane, Butane, LPG
200mm/7.9 x 45mm/1.8 x 90mm/3.5
Probe long stainless steel shaft, type K thermocouple and 3m/6ft long neoprene hose
(L) 300mm/7.9 x (Dia) 6mm/0.25 with 200mm/7.8
+32 - 104 F (0 - 40 C) 10% to 90% RH non-condensing
4 AA cells >8 hours using Alkaline AA cells
Input: 110 V AC / 220 V AC nominal
