Newport/Crompton 202A-P 100 PSI LED Panel Meter Display
Item appears to be in excellent condition.
Dimension (LxWxH")- 4 x 3 x 2
Model 202A-P is a low-cost 3 1/2 digit ( 1,999 count) process meter for applications where indication-only is required. It provides a span adjustment of 2,000 counts for all signals, a zero adjustment of 1,000 counts for input signals of 4-20 mA and 1-5 V and a zero adjustment of 1,500 to +500 counts for input signals of 0-10 V. Scaling and calibration are easily accomplished in the field by multiturn potentiometers accessible behind the lens. Accuracy is 99.9% of reading.
The 202A-P can also be used in ratiometric pot-follower applications to determine liquid level or valve setting from the position of a potentiometric wiper. The required external reference voltage can be derived from the meter's own 4.7 V dc supply.
The 202A-P is housed in a 1/8 DIN case that requires less than 4.1 in (104 mm) behind the panel. A screw-terminal barrier strip for signal and power is standard.
Options are isolated 9-32 V dc or 26-56 V dc power, a PCB edge connector for display control and output of +4.7 V dc and 4.7 V dc power, and a splash-proof lens cover which meets NEMA-4 requirements.
NMR, SIG HI to SIG LO: 56 dB, 50/60 Hz
CMR, SIG GND to SIG HI: 120 dB, DC to 60 Hz
CMR, SIG GND to PWR GND: 120 dB, DC to 60 Hz
CMV, SIG GND to PWR GND: 1500 Vp per HV test, 354 Vp per IEC spacing
Zero tempco: 0.01% of offset/ C
Span tempco, ratiometric: 0.01% of reading/ C
Span tempco, non-ratiometric: 0.03% of reading/ C
Warmup to rated accuracy: 1 min
Technique: Dual-slope, average value
Decimal points: Three positions, programmable by jumpers or at connector, 10 mA sink
Level: TTL or 5 V CMOS compatible
AC voltages: 115 or 230 V ac, 15%
DC voltages: 9-32 V dc, isolated to 300 Vp; 26-56 V dc, isolated to 300 Vp
Output voltages: +4.7 V dc and 4.7 V dc 5%, 10 mA max
Storage temperature: 40 to +85 C
Dimensions: Newport DIN2A (short 1/8 DIN) case (see Mechanical section for drawings)
