Cctv 540TV 10X ptz mini smartdome samsung camera module
1/4" 410K/470K Pixels Super HAD CCD
High Resolution 540 TV Lines (Color)/ 570(BW) TV Lines
Horizontally and Vertically speed 0.05 ~ 360 /s
x10(f=3.8~38 mm) Optical Zoom Lens (x10 D-Zoom)
Min. illumination: 0.7 Lux (Color) / 0.002 Lux (B/W) @ 50 IRE
High die-cast aluminum case construction
Adopt 1/4 Step Motor, Precision < 0.05 /S
The camera with X10 Optical Zoom and X10 Digital Zoom Lens
With the auto focus function, the image will be always clearer and quality
Built in IR cut Filter, it can auto switch at night to capture the sharpness image at night
OSD menu is provided to display the status of camera and to configuie the functions interactively.The information such as Camera ID, Pan/Tilt Angle, and Preset can be displayed on screen
When the unit is observing a wide area, the captured image can be masked for privacy purpose. User can easily configure the size and position of required privacy zones, up to 4 zones are available
Preset: 0.05 ~360 /s, Manual: 0.05 ~300 /s
Tilt : 180 (Auto-Flip On) , 90 (Auto-Flip Off)
128 presets (Label, Camera Image Setting)
8 tour tracks(20 action entities per Group)
4 Pattern, aboutp 5 minutes/pattern
Image Auto Flip, Auto Parking, Power-up Action,
