5MHZ signal sweep function generator frequency counter
5MHz Signal Sweep Function Generator Frequency Counter
For sale is a brand new, high quality digital signal generator at a very affordable price! The Quakko 5000 is an extremely versatile signal generator excellent for lab technicians and professionals in electronics industry, it allows continuous and accurate adjustment of frequency from 0.1Hz to 5 MHz, capable of producing high accuracy single waveforms including sine waves, triangular waves and square waves, both in single frequency mode and sweep frequency mode, as well as modulated signals using FM, AM, and PM, and Keying signals in ASK, FSK, and PSK. The Quakko 5000 can also be used as a high accuracy frequency counter, and can be controlled by a PC via RS232 interface. In addition, its digital keypad enables easy input of parameters.
* Output frequency: 0.1Hz to 5 MHz
* Output impedance: 50 Ohm or 600 Ohm selectable
* Output signal form: sine, triangle, and square wave range in 0.01 Vpp to 10 Vpp with 50 Ohm impedance (or 0.02 Vpp to 20 Vpp with open circuit)
* Function duty cycle: 1% to 99%
* Frequency stability: +/- 2 ppm
* Signal accuracy: sine wave distortion < 0.1%; triangle wave linearity > 99%; square wave rise and fall edge < 30 ns
* Modulated Output: modulation type - AM, FM, PM; Carrier wave - Sine wave, Triangular wave, Square wave; modulation frequency - fixed at 1000 Hz or 0.1-10Hz adjustable
* Keying singal: keying type ASK, FSK and PSK; Carrier wave - Sine wave, Triangular wave, Square wave; Rate - 0.1 to 10 Hz
* Sweep frequency: Waveform - Sine wave, Triangular wave, Square wave; Sweep time - 100ms to 10 s; Sweep range - 1Hz to 5MHz
* Frequency Counter: Range - 10Hz to 100MHz; Sensitivity - 25mV; Impendance - 1 MOhm
* Trigger: supports internal or external triggers, as well as single or multiple triggers
* Output attentuation: 20 db, 40 db, 60 db
