New 1" ball valves flowserve worcester & sharpe lot/6
Tube Bore Clean 1" Ball Valves
Up for sale are Five Worcestor 1" Series WK 74 & One (1) Sharpe 88 valve with a stainless steel body, pipe ends, ball and stem, TFE Body seals, quick disconnect ends, and electropolished finish Ball Valves. The style is a 3 piece valve, tube bore, bio-directional flow.
Flowserve Worcester Controls Series & Sharpeare clean valves that operate dependably in the pharmaceutical, biotech, food, cosmetic, paint, chemical and semi-conductor manufacturing industries where microbes, media deposits, mineral impurities and cross-contamination can threaten the quality of the product. The high-purity design, high vacuum rating, high cycle life and pressure/temperature rating of these valves make them ideal for applications from sterile steam to nutrient inlets to high-purity water. The performance of the WK 74 Tube Bore Clean Valve is based on a combination of high standard specifications.
Far as I can see, these valves are unused. Please refer to photos for closer inspection.
* Tube Bore: The inside diameter of the valve components are tube bore dimensions so that the valve precisely matches the tubing it is welded to. This prevents buildup of progens or bacteria.
* Low Ferrite Content: The valves are made of 316L stainless steel with a guaranteed ferrite content of less than 5%. This prevents rouging resulting from minerals and impurities drawn from higher ferrite content metals.
* High-Cycle Sealing, Bubble Tight Shut-off. Seats of RTFE, Reinforced RTFE provide bubble-tight shut-off through the valve.
* Steam Service Capability: TFM material with carbon and graphite fillers with excellent high temperature properties. These standard seats are capable of up to 275 working steam pressure making he WK 74 valve ideal for sterile steam applications.
* Seating Materials compatible with almost any media. Temperatures to 400 degrees F, pressures 500 psi.
* 3 piece design allows interchangeability of ends and easily maintained.
* Bottom entry stem for safety
* Simple 1/4 turn handle operation with visual indication of flow.
