R410 port tool adapter pair 1/4"sae mfl 5/16"ffl hvac
R410A System Port(5/16") Tool Adapter:
From Manifold And Other Service Tools(1/4" SAE FFL) to R410a System Ports(5/16" SAE MFL)
1/4" Male flare x 5/16" Swivel Female flare, also known as 1/2"-20 UNF Female.
THIS ADAPTER IS USED ON SOME **R410A A/C SYSTEMS THAT HAVE THE LARGER UNIQUE FITTING ON THE SERVICE VALVE, The description of that fitting is 5/16" SAE also known as 1/2" ACME Male-20UN.
This adapter will screw onto the 5/16" also known as 1/2" ACME MALE-20 UN fitting and allow you to connect a standard 1/4 service hose or other tools like oil injector or to it.
The female side of the brass adapter has a Schrader valve depressor so it will push in or depress the existing Schrader valve and the male end goes to the tool fitting.
R410a Adapter/Converter: 1/4" Male SAE to 5/16" Female SAE adapter Service Core Core Depressor Solid Brass
Needed by your AC manifold and other tools with 1/4" FFL connect fittings to work on R410A systems with 5/16" MFL service ports, for recovery and diagnosis, recharge, adding oil/dye, etc.)!
* One end, Swivel Female 5/16" SAE FFL (the common size of R410A manifold hose connector and R410A system service ports).
* This female fitting has a valve-core depressing device to open the valve when connected;
* This Female connector is free-moving, so that the other part does not turn when you tight or lossing the connection.
* Another end, Male 1/4" SAE MFL (the size of most AC system service tools like manifold hose connection, oil injectors, recovery units, vacuum pump, etc.).
* Serve as a connector/converter/adapter of your 1/4 " into 5/16" female SAE.
* 2 adapters in a pair for the selling price
