6 Tops-All Mold Clamps Hold Down Plastic Injection 10"
Lot of 6 Top-All Mold Clamps HD-110 Open Toe Style: Heavy Duty (with Swivel-Base Adjusting Screw)
* Clamping Screw Diameter - 1"
* Clamping Screw Size -1"-8 x 5"
* Mold Clamp Body Specifications - 1 " Thick x 2 " wide x 10" Overall length
* Base Screw Minimum Adjustment - 7/8"
* Base Screw Max Adjustment - 2 3/8"
Clamps are in excellent condition
If purchased new these clamps would cost over $75.00 each (6 X $75.00 =$450.00)
The swivel-based screw permits fast, sure adjustments, protects platen against scoring, eliminates threaded bolt hole distortions and reduces set-up time. With a tilting action, the swivel base even adjusts uneven platen surfaces.
* Quick and Easy Adjustment Reduces Setup Time
* Clamps Made from Premium Quality Steel,Hardened for Extended Life, and Coated with Black Penetrate Finish to Prevent Rust
* Unique Swivel-based Adjusting Screw Provides Maximum Flexibility and Accuracy
