Tektronix 3066 realtime spectrum analyzer
Tektronix 3066 Realtime Spectrum Analyzer
The Tektronix 3066 spectrum analyzer is a wide band, very sensitive receiver. It works on the principle of "super-heterodyne receiver" to convert higher frequencies (normally ranging up to several 10s of GHz) to measurable quantities. The received frequency spectrum is slowly swept through a range of pre-selected frequencies, converting the selected frequency to a measurable DC level (usually logarithmic scale), and displaying the same on the CRT of the Tektronix 3066. The CRT displays received signal strength (y-axis) against frequency ( x-axis).
Some applications for Tektronix 3066 Spectrum Analyzers include Site Monitoring: Verify that the frequency and signal strength of your transmitter is accurate. Interference: Before a system is installed you use a Tektronix 3066 spectrum analyzer to verify that the frequencies (you plan to use) are not occupied or if the presence of a very strong signal will interfere with your new setup. Interference can be created by a number of different situations. Other tests that utilize the Tektronix 3066 spectrum analyzer features include antenna isolation, co-channel interference, adjacent channel power, occupied bandwidth, intermodulation, microwave or satellite antenna alignment, and characterization of components.
Freq, time, mod domain analysi
Performance Characteristics of the 3066
Minimum Displayed Average Noise
Maximum Displayed Average Noise
Programmability/Connectivity of the 3066
