New artesyn NLP65-9608 dc power supply 65W 5V 12V -12V
NEW Artesyn NLP65-9608 DC Power Supply 65W 5V 12V -12V
* Output 1: +5V 7.5A (8A with fan, 9.1A peak)
* Output 2: +12V 2.5A (3A with fan, 3.3A peak)
* Output 3: -12V 0.65A (0.8A with fan, 0.81A peak)
* Output Power: 65W (75W with 20CFM fan cooling)
* 125% Overvoltage protection
* Short Circuit protection: continuous, cyclic operation
* Switching frequency: 100kHz
* MTBF: >150,000hrs (MIL-HDBK-217F)
* Temperature: Operating 0 -70 C, Storage -40 -85 C
* Dimensions: 5" x 3" x 1.26"
* UL, CSA, VDE, CE agency approvals
* Current list price (from Newark): $76.09
Please NOTE: This power supply needs a load of 0.25A to maintain proper output voltages. With no load, the outputs will vary close to (but not exactly match) the rated output voltage.
