Atten AT5011(a) spectrum analyzer+tracking generator 1G
AT5010 /AT 5011 is the perfect instrument for analyzing any kind of signal within the frequency range of 0.15 to 1050 MHz, and is best suited for meeting the RF measurement needs of education and industry.
* Frequency Range : 150KHz to 1050MHz
* 4 Digit Display : Centre & Marker Frequency,
* Amplitude Range : -100dBm to +13dBm
* Filters : 20KHz, 250KHz & Video Filter.
* Output Power : +1dBm to -50dBm (50 ohms)
* Built-in Tracking Generator : 0.15MHz to 1050MHz (Only for Model AT5011+)
This items has Tracking Generator: (0.15MHz to 1050MHz)
AT5011+ Tracking Generator Specifications
* Output Frequency Range : 150KHz to 1050MHz.
* Output Power Level : -50dBm to +1dBm (in 10dB steps & Variable).
* Output Attenuator : 0 to 40 dB (4 x 10 dB steps).
* Output Attenuator Accuracy : 1dB.
* Output Flatness (150KHz to 1050MHz) : 1.5dB.
* Spurious Outputs: Harmonic Spurs & Non harmonic Spurs( RFI): <20dBc.
* Output Impedance : 50 ohms (BNC female).
Frequency Response(Relative to 250MHz,
Intermodulation (3rd order) (Spurious Response)
+10dBm, (0dB attenuation), DC : 25V
