The OMB-TEMPBOOK-66 data acquisition system adds voltage and thermocouple measurement capability to notebook PCs for portable test applications and also provides an effective alternative to plug-in boards for desktop PCs. The OMB-TEMPBOOK-66 provides 12-bit, 100 kHz data acquisition and data transfer to a PC via an enhanced parallel port (EPP) interface or PCMCIA link. The unit can also connect to a standard PC parallel port and can transfer readings directly to disk at 30K to 50K samples per second depending on the computer. An external module with the same footprint as a typical notebook PC, the OMB-TEMPBOOK 66 can be attached directly under a notebook PC for portability.
THERMOCOUPLE AND VOLTAGE INPUTS
The OMB-TEMPBOOK-66 has a built-in analog capability that permits it to measure eight channels in differential input mode or 16 channels in single-ended mode. Its on-board programmable gain instrumentation amplifier can be set to gains of x1, 2, 5, 10, 20, 50, 100, or 200 on a per-channel basis. Its A/D converter scans selected channels at a constant 10 sec/channel rate, minimizing the time skew between consecutive channels. The time between the start of each scan sequence can be programmed to start immediately or at intervals of up to 10 hours.
The OMB-TEMPBOOK-66 features a hardware-based digital/TTL trigger that minimizes trigger latency to less than 10 sec. The OMB-TEMPBOOK- 66 can also be triggered from a command from the PC.
- Omega TempBook/66 User Manual Guide
- Omega Vanzetti Thermal Monitor P/N # 3042-A-1-F-1-R3-0-M
