200A acdc tig arc pulse welder 50A plasma cutter 200AMP
IGBT Inverter Welder with Pilot Arc Plasma Cutter
TO DOWNLOAD A MANUAL CLICK HERE
AC & DC Pulse Tig Arc Cut (MMA)
50A Plasma Cutter and 200a Arc and TIG Welder Combo
Genuine Infineon IGBT based electronics
Operating Voltage: 220/230/240 VAC 50/60Hz Input
Open Circuit Voltage: 60-80V
60% Duty Cycle @ Rated Amperages
Thermal Overload Protection
Plasma Cutting Specifications @ 65psi:
3" Per minute @ 7/8" Steel (Severance Cut )
17" Per minute @ 1/2" Thick Steel Minimum requirement for air compressor: 3.5 cfm
Up Slope, Down Slop Control: 0-10 Seconds
Base Current Control: 5-200 Amps
Peak Pulse Current Control: 5- 200 Amps
Pulse Frequency Control: .5-25 Hz
Pulse Width Control: 10%-90%
AC Frequency Control: 20-100 Hz
AC Balance Control: 30-70% (for Aluminum)
Whether you are interested in fabrication, general repair, HVAC,
or any other type of work, you will find that the combined features
of this unit are suited to just about any welding or cutting task that
you might have. Aluminum, Stainless Steel and Mild steel are not a problem
for the PowerMaster. Thin sheet metal, aluminum and exotic metals can be
easily welded in the TIG mode. The pulse feature can be selected while in
the TIG mode to control heat input on heat sensitive metals. The PowerMaster s
built in plasma cutter will cut through any metal, including expanded metal,
thanks to the pilot arc . With a quick flip of the switch, the stick (SMAW)
function is on hand to make quick field repairs or sound, quality welds in
the industrial setting. So, if you want convenience and capability, you will
always have the right tool for the job with an Everlast PowerMaster.
PILOT ARC TORCH Increase
