13" swg 36" cc clausing-colchester 6525 engine lathe, t
13" Swg 36" cc Clausing-Colchester 6525 ENGINE LATHE, T
13" Swing 36" Centers Clausing-Colchester 6525 ENGINE LATHE, Threads, 3 HP, 3-Jaw, Toolpost, FacePla
13" x 36" CLAUSING COLCHESTER ENGINE LATHE
MODEL: 6525, S/N 3/6567E, NEW:1960'S
SWING OVER BEDWAYS ................... 13"
SWING OVER CROSS SLIDE ............... 8"
HOLE THRU SPINDLE .................... 1-9/16"
DISTANCE BETWEEN CENTERS ............. 36"
SPINDLE NOSE ......................... L-O
SPINDLE SPEED RANGE (16) ............. 39 - 1500 RPM
ENGLISH THREADING RANGE (45) ......... 4 - 112 TPI
FEED RANGE (45) ...................... .0025" - .068" IPR
TAILSTOCK SPINDLE TAPER .............. #3MT
TAILSTOCK SPINDLE TRAVEL ............. 4-1/4"
APPROX FLOOR SPACE ................... 64"L x 32"W x 49"H
APPROX WEIGHT ........................ 1,750 LBS
