Trinocular compound microscope infinity plan objectives
Trinocular Compound Microscope
This microscope is designed for professionals. The M9332 microscope features large double-layer mechanical stage, two pairs of 10X and 15X super wide field eyepieces, and four high quality infinity-corrected plan objectives. A 3W LED light provide safe and bright illumination. Reverse nosepiece makes it easy to access the slide and helps to protect the objectives from damage or smear. Large double layer mechanical stage can hold two slides, and is special designed that no translational guide sticks out anymore, safe and neat.
40X, 60X, 100X, 150X, 400X, 600X, 1000X and 1500X
A pair of widefield 10X/20 (diopter adjustable)
A pair of widefield 15X/16 (diopter adjustable)
Infinity corrected, plan, achromatic objectives
4X/0.10 ( /-), 10X/0.25 ( /-), 40X/0.65 ( /0.17, spring), 100X/1.25 ( /0.17, spring, oil)
Trinocular, 30 Inclined, 360 rotatable
Hinged interpupillary distance adjustment: 50 mm - 75 mm
Range 2-1/16" x 3" (53 mm x 78 mm)
Dimension 7-3/8" x 5-5/16" (188 mm x 135mm)
Abbe NA1.25 w/ iris diaphragm and filter holder
Coaxial coarse and fine focusing knobs on left side.
Fine focusing knob on right side.
Transmitted, 3W LED light (equivalent to 30W halogen)
12-3/4" x 9" x 18-3/4" (35 cm x 23 cm x 47.7 cm)
* 4 DIN objectives: 4X, 10X, 40X and 100X
* Blank slides and cover slips
Click the button above to view the list of accessories compatible with this product M9332
