New st STM8S-discovery development tool; demo board mcu
ST STM8S-Discovery Development Tool; Demo Board MCU New
1 STM8S-Discovery Module (Perforated)
The STM8S-DISCOVERY is a quick start evaluation board which helps you to discover the STM8 features, and to develop and share your own application. It is based on an STM8S105 and includes an embedded debugger, ST-LINK, and a touch sensing button. Numerous applications are available from the STM8S-Discovery web page.
- STM8S105C6T6 microcontroller, 32KB Flash, 2KB RAM, 1KB EEPROM
- Selectable power of 5V or 3.3V
- Extension header for all I/Os
- Wrapping area for users own application
- USB interface for programming and debugging
