Analog Digital Breadboard Design Proto Kit w 3 Power Supplies
LED DISPLAY 4X7 CLOCK LTC-3710HR
RESISTOR SIP 8PIN BUSSED 4308R-101-472
4.7K .1SP 1 COMMON 7 RESISTORS
SWITCH PCB PUSHBUTTON VERTICAL TACTLE
SPDT MOMENTARY MERITEK DTSG-61K
RESISTOR SIP 8 PIN 4 RESISTORS
10K .1SP 4308R-102-103 BOURNES
CAP 1000 uF RADIAL 25V 5mm200mil SP
ELECTROLYTIC +-20% 13X15MM520mil W
ELECTROLYTIC +-20% GREY ILLINOIS CAPACITOR
CAP .1uF 63V 5% TH BYPASS SQUARE
QUALITY METAL POLYESTER FILM .2 SP .1J63M 85C
39K OHMS 5% 1/4 W R25XT68J393 ROHM
5.1K OHMS 5% 1/4 W R25J5K100 ROHM
BREADBOARD SOLDERLESS 830 POINTS
64x5x2 QTY POWER STRIP 4X50 +-
POWER SUPPLY BREADBOARD +5V PCB KIT
POWER SUPPLY BREADBOARD +12V PCB KIT
POWER SUPPLY BREADBOARD +3.3V PCB KIT
SCREW TERM & PLUGIN SEMTECH EZ1585CT-3.3
3BNC UNSOLDERED 1X6 .1SP PLUGIN
DB25 F BREADBOARD PLUG ASSY W/PINS
* Learn to use the ULN2003 Open Collector Driver for high current loads.
* Learn to use the LM324 Op Amp, the most commonly used operation amplifier out there.
* Learn to use a Mux Chip to multiplex 8 analog lines into 1.
* Learn how a very common 4x7 segment LED Display works (clock or counter).
* Learn to use pushbutton switches with pull-up resistors.
* Learn to use rocker switches with pull-up resistors.
* Learn to make timing circuits with capacitors and resistors.
* Connect to your scope and function generator.
For a Complete Parts List with individual product pictures and links to PDFs, click here.
For a Complete Parts List with individual product pictures and links to PDFs,
