Hamada VS34LSII + 2 kompacs + 2ND color head + powder
* Kompac Dampening on BOTH Heads!
* Rollback Satellite 2nd Color Head
* Condition: We deinstalled this press last week from the continued operations of a small print shop. They were printing on this press right up to the deinstall. With Kompac's on BOTH heads, this is an option-rich press and was kept in excellent condition.
* HAMADA VS34LSII 2-Color Offset Delivers Amazing Control and Convenience. The VS34 series is an A3 wide portrait press with a pin-bar plate clamp system. It provides excellent accuracy and repeatability, so it is suitable for printing that requires high quality and enables printing involving color registration by two or more passes. Standard features: Pre-Load Feeder, Automatic Blanket Washer, Static Eliminator, Mechanical Double Sheet Detector, Centralized Lubrication, Electronic Jam Protection, Delivery Air Shower, Feeder Air Shower, Auto Receding Delivery Pile, Push Guide Registration
* Rollback Satellite 2nd Color Head: This turns any single color press into a 2-Color press, doubling your production ability on multi-color jobs! Additionally, it stays in register to the main head when you roll it back, as opposed to a Townsend Swing-Away that needs re-registered every time you swing it away. *New Cost: $7000*
* Kompac Dampener on Main Head: This is an amazing dampening system that allows the press operator to effortlessly control dampening and spend his time focusing on the printing. *New Cost: $3500*
* Kompac Dampener on Rollback Head: It is uncommon to see a Kompac on a printing press (or at least it's a special bonus). But it is very rare to find a Kompac on the 2nd Head also! These things aren't cheap! *New Cost: $4200*
* Hamada Powder Spray System: This is a nice powder spray unit. *New Cost: $1400*
* Operator-friendly operation increases efficiency. The convenient control panel comes equipped with a preset repeat counter, double sheet detector switch and a blanket jam detector switch. Additional important indicators and switches are also located on the panel.
-*Specs are obtained from the internet and checked for reasonability only, please check all specifications independently to ensure accuracy.
* Maximum Paper Size: 13 3/8" x 17 3/4"
* Minimum Paper Size: 3 1/2" x 5 1/2"
* Maximum Printing Area: 12 7/10" x 17 1/4"
* Paper Thickness: 0.04" ~ 0.3"
* Printing Speed: up to 10,000 iph
* Metal Plate Type: Pin bar / straight edge; 25 holes, 0.5" pitch
* Feeder Pile Capacity: 19 5/8"
* Delivery Pile Capacity: 19 5/8"
